aquasource® XS

Reading time:

aquasource® XS is a standard water treatment system using ultrafiltration membranes. It is a compact and autonomous solutions, easy to integrate. With flow rates ranging from 1 to 16 m3/h per unit, the aquasource® XS will attract small communities, industrials, or professionals from the private sector (hotels, hospitals, holiday centers…).

The system is compact (2.30 x 1.05 x 2.20m), ready to connect electrically and hydraulically, and has a quick commissioning time (< 48h), allowing a rapid set up even in exiguous buildings. The aquasource® XS is fully automated: an integrated standard automaton monitors all the sequences of the process such as filtration, backwashing, alarms, and membrane regeneration.

aquasource® XSSecured image
Table 13. aquasource® XS technical data
aquasource® XS - Ouhans (France)Secured image
Photo 30. aquasource® XS - Ouhans (France)

In order to avoid on-site travels, the operator can monitor and change via a smartphone or a computer the operating parameters of the system (filtration, backwashing, on/off function, and possible alarms). This remote access allows to limit on-site travels and to ease the work of the operator.

In case of need, SUEZ also proposes to assist the operator remotely, by proposing the hand in or analysis of the system operation in order to optimize its operation.

Due to a simple addition of modules, the aquasource® XS is an investment for the future as it meets the evolution of needs in water .
