compact lamellar settling – Sedipac®
Combined treatment for grit & grease removal and primary settling functions.
The Sedipac® range includes primary lamellar clarifiers for urban wastewater treatment.
- Sedipac® D is a proven lamellar primary settler. Its main function is the separation of decantable suspended solids from raw water. It is installed downstream of a conventional pretreatment (screening, sand and grease removal).
- Sedipac® 3D combines in a single device the functions of sand removal, grease removal and primary settling. It is installed directly after the screening.
- New Turbo versions allow to reach even higher settling velocities (18 m/h).
key figures
- High velocity of treatment: 10 to 25 m/h
- 3 times more compact than a conventional primary settling tank
- 3 functions of pretreatment in 1 single work
among our references
- Xiamen (China) 1,200,000 PE(Sedipac® 3D)
- Central Manila (Philippines) 800,000 PE (Sedipac® Turbo 3D)
- Bourges (France) - 140,000PE (Sedipac D)
- Laon (France) 45,000 PE (Sedipac® Turbo D circular version)
- La Roche-sur-Yon (France) 120,000 PE (Sedipac® Turbo D)
profit
- A very compact solution
- Clear water with high treatment speeds without any chemicals
- A large range with different constructive arrangements:
- Rectangular shape with modular design allowing parallel installation of several devices
- Circular shape to further reduce the environmental footprint
- Easy to operate: device for recovering floating material
- Easy to cover: olfactory impact under control
