coding principle

Reading time:

Functional identification comprises two to four upper case letters, in two parts :

  • 1st part: first letter or variable and its modifier, which is common to all the instruments on the same loop;
  • 2nd part: following letters identifying the functions (table 83).
table elements coding equipmentSecured image
Table 83. Identification table of the elements used for coding a function or an item of equipment
