lamellar and sludge contact clarifier – Densadeg®

lamellar and sludge contact clarifier – Densadeg
Clarifier with optimized flocculation using external sludge recirculation

The Densadeg® treats all types of water. In drinking water treatment, the Densadeg® is used for clarification (removal of suspended solids, colloids, color, micro-algae, etc.), carbonate removal (softening).

It combines the principle of lamellar settling with an integrated sludge thickener. No need of additional sludge thickening equipment before dewatering. The densification of sludge allows to reduce the volume of extracted sludge and thus limit the water loss.

Clarificateur compact lamellaire à contact de boues – Densadeg schemaSecured image

key figures

  • Sludge > 30 g/l
  • 5 to 8 time smaller footprint than traditional settling unit
  • Application to river water or dam water (from 5 to 5000 NFU)

among our references

  • Over 600 References
  • Yangshupu (Chine) - 360,000 m3/d
  • Morsang-sur-Seine - 84,960 m3/d
profit
  • Very low water loss
  • Compactness due to its modular and lamellar design
  • Integrated sludge thickening - particularly suitable in case of small footprint or if water loss should be limited
  • Fast and easy operation even in case of important variation
